VIMERCATI PHSY 150 X 3050 CNC press brake

VIMERCATI PHSY 150 X 3050 CNC press brake was built in 2011 in Italy by VIMERCATI s.n.c. The rigid, internal stress-free design, combined with reliable components, makes the machine ideal for even the most intensive machining of workpieces with a maximum length of 3050 mm. The machining process is performed by a slider operating with a force of 150 tonnes, which is guided on double external and internal sliding guides. The back stop, on the other hand, is driven by brushless servomotors, which ensure achievement of high feed rates combined with excellent positioning precision. The HCL (Hydraulic Crowning Linear) system, patented by VIMERCATI, allows for perfect bends to be realised both in the centre of the press and on its sides. The result is perfect bending uniformity, confirmed by the same angle over the entire length of the bent part, regardless of its type or dimensions. The PHSY 150 X 3050 CNC hydraulic press brake also features a wide range of equipment, including among others an intuitive CYBELEC CNC control, a measurement and motion control system for the Y1, Y2 axes and tools. The total weight of the machine is 15000 kg. Technical specifications of the VIMERCATI PHSY 150 X 3050 press brake maximum press force: 150 t maximum workpiece length: 3050 mm approach speed: 200 mm/s bending speed: 0-10 mm/s return speed: 120 mm/s X axis feed rate: 650 mm R-axis feed rate: 100 mm R-axis stroke: 170 mm Y-axis stroke: 270 mm maximum tilt on Y axis: ± 10 mm distance between columns: 2550 mm work table height: 910 mm distance between work table and slider: 460 mm reach: 500 mm Y-axis positioning accuracy: 0.01 mm X-axis positioning accuracy: 0.05 mm R-axis positioning accuracy: 0.1 mm operating hours: 2022 h main motor power: 15 kW oil tank capacity: 275 l dimensions (L x W x H): 4450 x 2050 x 3200 mm weight of the VIMERCATI PHSY 150 X 3050 machine: 15000 kg Equipment of the VIMERCATI press brake CNC controller: CYBELEC ModEva 12S upper safety photocells hydraulic compensation HCL (Hydraulic Crowning Linear) ATC system (Automatic Thickness Control) for sheet metal thickness control, design of tools for extreme loads and optimisation of the bending angle AFC system (Automatic Frame Control) to control the deflection of the columns during bending, thus automatically correcting the bottom dead centre, i.e. the punch penetration value inside the die Y1, Y2 axis measurement and motion control system based on 2 HEIDENHAIN optical scales back stop with brushless servo motor in each axis PROMECAM type extensions H=100 2 driven stop fingers (Z1-Z2/Xrel) efficient hydraulic system with components from well-known brands such as BOSCH-REXROTH, EDI SYSTEM, or SAUER DANFOSS reliable electrical system with components from well-known brands such as SIEMENS and TELEMECANIQUE complete set of tools manual central lubrication foot switch control supports on linear guide adjustable in height positioning and levelling plates set of service spanners electrical and mechanical covers according to CE standards operating and maintenance manual CE certificate
